Features:
1. Direct DC 48V powered, no conversion process.
2. Easy installation, very similar like the traditional air conditioner.
3. Not limited by power supply and climate.
4. Full DC 3D control (adopt world well know DC compressor, DC indoor fan motor and DC outdoor fan motor), reliable running and high efficiency.
|
Model |
KFR-26G/1P |
KFR-35G/1.5P |
KFR-50G/2P |
||
|
Power supply |
DC48V |
DC48V |
DC48V |
||
|
Cooling |
Capacity |
Btu/h |
9000 |
12000 |
18000 |
|
Input |
W |
475 |
635 |
888 |
|
|
Rated current |
A |
9.89 |
13.23 |
18.5 |
|
|
Heating |
Capacity |
Btu/h |
9500 |
13000 |
19000 |
|
Input |
W |
462 |
620 |
885 |
|
|
Rated current |
A |
9.63 |
12.92 |
18.43 |
|
|
Max. input consumption |
W |
1050 |
1200 |
1500 |
|
|
Max. current |
A |
21.87 |
25 |
31.25 |
|
|
Starting current |
A |
1.5 |
2 |
3 |
|
|
Application area |
m2 |
10-20 |
15-25 |
25-40 |
|
|
Solar panel |
330W×4 |
330W×6 |
330W×8 |
||
|
Solar controller |
48V/30A |
48V/50A |
48V/50A |
||
|
Battery |
12V/120AH×4 |
12V/180AH×4 |
12V/250AH×4 |
||
