Features:
1) High efficiency and energy saving, electricity cost is only 1/4 of electric water heater
2) Automatic microcomputer control, operate properly all the year round and will not be influenced by the climate
3) World top brand compressor for heat pump—Panasonic compressor (joint venture with Wanbao)
4) Automatic defrosting, continuously provide hot water even in cold areas
5) No waste heat, exhaust gas, waste residue, no pollution to the environment
6) Operating temperature: -10℃ to 43℃
7) Water tank: 100L, 150L, 200L, 250L, 300L, 400L, 500L
|
Model
|
KFX70/1HP
|
KFX110/1.5HP
|
KFX150/2HP
|
|
Voltage
|
220V
|
220V
|
220V
|
|
Rated Input Power
|
0.8 Kw
|
1.2 Kw
|
1.9 Kw
|
|
Max. Input Power
|
1.2 Kw
|
1.8 Kw
|
2.5 Kw
|
|
Rated Current
|
3.6A
|
5.5A
|
8.5A
|
|
Max Current
|
5.5A
|
8.2A
|
11.5A
|
|
Rated Hot Water Temp
|
55℃
|
55℃
|
55℃
|
|
Max Hot Water Temp
|
60℃
|
60℃
|
60℃
|
|
Rated Heating Capacity
|
3.25 Kw
|
5.1 Kw
|
7 Kw
|
|
Hot Water Produced Volume
|
70 L/h
|
110 L/h
|
150 L/h
|
|
Noise
|
≤43 dB(A)
|
≤43 dB(A)
|
≤43 dB(A)
|
|
Dimension
|
980*265*550mm
|
980*265*550mm
|
980*265*550mm
|
|
Weight
|
42 Kg
|
45 Kg
|
51 Kg
|
|
Rated Water Pressure
|
0.3-0.6 Mpa
|
0.3-0.6 Mpa
|
0.3-0.6 Mpa
|
|
Connection dimensions
|
DN20
|
DN20
|
DN20
|
|
Auto-Defrost
|
Yes
|
Yes
|
Yes
|
|
Current Protect
|
Yes
|
Yes
|
Yes
|
|
Microcomputer Control
|
Yes
|
Yes
|
Yes
|
